Description

Application possibilities

This model is our basic model, the threshold aid is suitable for almost any application and available in heights from 2 to 7 cm. Due to the slope of almost 0 mm and a width of 90 or 100 cm, the Basic Line threshold aid is suitable for making a space accessible for practically any aid or vehicle.

Straight side surfaces

The straight side surfaces allow the entire surface of the threshold aid to be used and a longer length can easily be achieved by placing several threshold aids next to each other.

Good slope angle

The Basic Line threshold aid is equipped with a good angle of inclination. This makes it less steep and easy to drive with an infusion trolley, walker, wheelchair or mobility scooter

Maximum load

Do you have a heavy mobility scooter or do you want to ride the Basic Line threshold aid with large equipment? No problem! This threshold aid has been tested and found suitable for a load of 2500 kg.

Technical details:

Article number:	244020
Dimensions (H x W x L):	H x W x 90 or 100 cm
Weight:	tbd
Colour:	Black
Product composition:	100% recycled rubber
Maximum loadable weight:	2500 kg
Application possibilities:	Mobility scooter, electric wheelchair, infusion cart, walker, electric bicycle, forklift, roll container, etc.
Available heights:	Increasing from 2 to 7 cm

* dimensional tolerance of 5%

Many heights available(See table)

We can supply the threshold aid in heights varying from 2 to 7 cm. Increasing in steps of 1 cm.

Height	depth	width	Slope angle
2.0 cm	16 cm	90 or 100 cm	12.5%
3.0 cm	30 cm	90 or 100 cm	10%
4.0 cm	40 cm	90 or 100 cm	10%
5.0 cm	50 cm	90 or 100 cm	10%
6.0 cm	60 cm	90 or 100 cm	10%
7.0 cm	70 cm	90 or 100 cm	10%

Assembly

You can easily place the Basic Line threshold aid in place. It will stay in place due to its weight.

If you do want to attach the threshold aid to the surface, you can do this with Bostik Superfix kit or you can use double-sided tape. You can find this in our webshop under the heading Fasteners.

Because the threshold aid is made of rubber, it is easy to work with. This makes it possible to drill holes in the threshold aid and then screw it in place.
